Plastic hot wedge welding machine Geomembrane welding machine

Plastic hot wedge welding machine Geomembrane welding machine
Geomembrane Welding Machine can weld geo-membrane of various thickness and are applicable for welding of all thermal-fused material such as PE,PVDF,LDPE, PVC, HDPE, EVA, PP and HDPE,EVA,PP.
Phone : +86 17564509768
Email : sales@drgeomembrane.com
Whatsapp : +86 17564509768
Product Description
  Model  BT-810
  Rated voltage  230V/customized
  Rated power  800W/1100W
  Frequency  50/60HZ
  Heating temperature  50-500℃
  Welding speed  1-5.5m/min
  Welding material thickness  Single layer film thickness
  Rubber wheel 0.3-1.5mm
  Steel wheel 1.0-2.0mm
  Welding seam width  Three seams: 16mm*3, cavity 12mm; two seams: 17mm*2, cavity 12mm
  Weld strength  ≥90% base metal (tensile strength in shear direction)
  Overlap width  10cm
  Insulation level  Class II
  Body weight  7.5kg


HDPE Geomembrane Liner for Welding Hot Melt Plastic Film Welding Machine Geomembrane for Pvc PVC Welding Machine

Tips:

1. For welding membrane with thickness below 1.0 mm, the silica pressure roller is the suitable choice.

2. For welding membrane with thickness above 1.0mm, the steel pressure roller is the best choice.

3. If the material is PVC, this model can weld from 0.2-2.0mm, and you can choose to assemble it with steel hot wedge.

4. Any customized demands, you can ask us directly. We have professional technicians team.
